The DM-550 is a five-channel dimmer designed for integration with existing 12–24V DC power systems, offering advanced control in a compact, rugged form. Ideal for multi-color LED configurations such as RGBAW or RGB+CCT, the DM-550 features four built-in color blending switches that allow users to program a base color into Channel 1 and blend it evenly across the remaining four channels at adjustable power levels. This intuitive interface enables precise control over complex color scenes without the need for external programming. Rated for 10 amps per channel and housed in a fully enclosed, IP65-rated steel chassis, the DM-550 delivers reliable performance in both indoor and protected outdoor environments. Its powder-coated 16-gauge steel enclosure ensures durability, while its low-profile footprint makes it a strong fit for permanent or mobile installations alike.
Specifications:
- Universal input: 12-24V DC
- IP65 rating, fully enclosed
- 10A x 5 channel dimmer rating
- Power coated 16ga steel chassis
- Four color blending switches
- Size: 6.625” x 3.25” x 1.25” (incl. knobs)
- Weight: 11 oz.
